DC2150

DC2150-Chassis_Front  1000px        DC2150-Modul_50S  1000px

Datenblatt


PDF Download

Directional Coupler 850 – 2450MHz

The DC2150 is a directional coupler operating at L-Band (950 – 2150MHz) and extended L-Band frequency range (850 – 2450MHz). It is especially designed for operation in combination with our RF power meter. PwrM3G but can of course also be used independently. A specially designed 1RU/19″ rack mount panel allows insertion of up to 8 DC2150 directional couplers.

SPL Serie

Product_SPL-1201_2-way-passive-Splitter-Combiner_crop SPL-1801_8-way-passive-Splitter-Combiner 1000px SPL-1201_Mounting-Panel 1000px

Datenblatt


PDF Download

Extended L-Band 2-way passive Splitter/Combiner

The 2-way Splitter/Combiner SPL1201 from our SPL Series is a high quality passive L-Band Splitter/Combiner module housed into a robust and compact aluminium enclosure. It can be used for standalone operation but also can be integrated into a corresponding 19″ rack mount panel for installation into a 19″ cabinet. It operates at the extended L-Band frequency-range (850 – 2450MHz) ready for KA-Band and HTS applications and is available with 50Ohm SMA(f)/BNC(f) or 75Ohm F(f)/BNC(f) connectors. This passive Splitter/Combiner features high quality, excellent RF performance and is perfectly suited for Satellite-, Broadcast and Broadband RF distribution infrastructures such as for Teleports, Earth-Stations or Cable/IPTV headend operations.


ITC5075

Product_IITC5075 582px

Datenblatt


PDF Download

Low loss impedance-converter, L-Band

The L-Band Impedance matching pad ITC5075 is ideal for flexible and fast matching between 50Ohm and 75 Ohm systems in L-Band frequency range.

It can be easily connected to relevant units like IRD´s, Receivers, Modems, optical fiber TX/RX…while it also assures quality and excellent RF performance with low loss of <0,3dB.
