RF-Design Produkte


LSCX414

 LSCX414_Front 1000px      LSCX414_Rear 1000px

Datenblatt


PDF Download

4-way active Hybrid L-Band Splitter/Combiner TX/RX System

The LSCX414 is a 4-way active hybrid L-Band splitter/combiner at a size of a 1RU/19” rack mount chassis only. The unit is especially designed in particular for VSAT terminals, SNG/DSNG operations but also for other satellite uplink/downlink applications such as small teleports e.g. to interconnect a corresponding number of satellite modems or other devices with it.

unten_ori
li_ori
rf-Logo_RZ_ohne_klein

LSC Serie

LSC408-L-Band-Splitter-Combiner_Front_3D-600px       LSC408_Rear_crop 1000px

Datenblatt


PDF Download

Modular 8-way L-Band Splitter/Combiner System with 1:1 Amplifier

The LSC series represents a high quality modular L-Band splitter/combiner system suited for versatile RF distribution applications where accurate RF power, high stability and availability is necessary. The system combines the LSC102 (dual splitter/combiner chassis) and the LSC408 (octal splitter/combiner chassis) together with the corresponding 1:8 splitter module (LSM2150-8) and the 8:1 combiner (LCM2150-8) module, each coming with built in 1:1 redundant adjustable amplifier.

The LSC102 chassis has 2 slots for population of max. two 8-way L-Band splitter and/or combiner modules while the LSC408 has 8 slots for insertion of max. eight 8-way splitter/combiner modules.

The LSC series with its flexibility, beneficial features and outstanding RF performance certainly is a perfect fit for any RF distribution infrastructure and perfectly suited for applications in Satellite Earth-Stations, Teleports as well as Broadcast infrastructures.
